Internal Trailer Washout Equipment & Sanitization System
Equipment. Chemistry. Data.
The SMART Washout by Whiting Systems, Inc. (WSI) helps food transportation operators implement and document sanitary practices that meet FDA and FSMA expectations reducing the risk of cross contamination, audit findings, and public food safety incidents that can damage brand trust and
customer confidence. Most washout systems clean trailers, ours manages sanitation.
for Refrigerated (Reefer) Vans,
Trailers and Containers
Cleans. Sanitizes. Protects.
Built Stronger.
All-Stainless Steel Construction
Full stainless framework and skin for long-term durability and corrosion resistance in harsh wash environments.
Inverter-Driven Lift System
SMART Gate loading gently lowers and raises ramps eliminating structural stress caused by momentum-based systems used by competitors.
Advanced Self-Centering Technology
Three-point centering with horizontal guides, lower guides, and proprietary software alignment significantly reduces the risk of vehicle hang-ups and deployment errors.
Built SMART(er).
Clean, electric technology
SMART Washout uses a networked, inverter-driven electric system which is cleaner technology vs traditional hydraulics others use. This means over the SMART Washout's lifetime, you are saving due to:
Variable speed control
Adjustable water volume and pressure
Precise chemical application
Precise electric control
Reduced maintenance (no hydraulic pumps, valves, or filters)
Minimized downtime usually experience due to hydraulic leaks
No contamination risk from hydraulic leaks
One efficient electric motor operating at optimized load levels
You gain flexibility, lower lifecycle costs, and improved process control.
Intelligent Pneumatic & Water Control
Network-controlled pneumatic cylinders and valves allow:
Directed wash, rinse, chemical, or high-pressure water to any spray manifold
Debris sweeping in the trailer nose
Single feed hose operation with full directional control
The result: cleaner trailers with less mechanical wear and greater operational efficiency.
Smart Automation & Reduced Complexity
Minimal external sensors (only two required for positioning and safety)
Software-driven control architecture
Trailer Presence System prevents deployment without proper trailer positioning
LED stop guidance for accurate docking
Pre-configured wiring harness reduces install time and field errors
Data, Monitoring & Flexibility
Real-time data logging with export capability for FDA / FSMA compliance
Remote diagnostics and monitoring via secure connection
Optional external docking station for non-dedicated dock facilities
Freeze protection, blow down capability
Dual-mode functionality: SMART Washout or MultiGun operation from one touchscreen interface
Total sanitation, not just cleaning
Full-Trailer Chemical Application
Application-based chemicals are applied to the entire trailer, not just the floor.
Advanced Disinfecting System
Advanced 15-20 Micron fogging / misting system for complete interior coverage.
Isolated Chemical Delivery System
Chemicals do not run through the main pump, extending equipment life and preventing scaling. No mix tanks prone to leaks or flooding.
The bottom line...
Other companies have systems that wash.
The SMART Washout by Whiting Systems Inc. delivers controlled, automated, full-trailer sanitation built for durability, precision, and operational accountability.
